JuLI™ Stage - Acquire Cell Images directly in your Incubator

Automated Cell Imaging System

Description

JuLI™ Stage is a fully-automated and digital fluorescence imaging analyzer that directly acquires cell image from various cell culture dishes in a cell-culture incubator.



This also enables users to support the quantified cell confluence results with low variation and the growth curve using image based analysis for bright field. JuLI™ Stage is equipped with a fully automated x-y-z stage and multi-channel fluorescent colors to acquire cell images and videos from various cell culture plates (up to 384wells) and dishes in an incubator. It also enables users to obtain quantified cell confluence results with low variation as well as the growth curve using image based analysis for a bright field. JuLI™ Stage is a Real-Time CHR (Cell History Recorder) designed for live cell imaging and analysis.

JuLI™ Stage has a wide range of applications as follows:

  • Wound healing
  • Apoptosis & Cytotoxicity
  • Cell proliferation
  • Fluorescence expression
  • 3D-spheroid culture
  • Stem cell monitoring
  • Cell growth monitoring
  • Differentiation of neurons
  • Angiogenesis … and more

Key features & benefits:

  • Incubator-compatible: Can be installed and operated in a cell culture incubator
  • Fully automated X-Y-Z stage
  • Interchangeable objective lens (4x, 10x, 20x)
  • Manual & auto focusing
  • Compatible with various plates & vessels
  • Data management with all-in-one PC

Supplier

NanoEntek Inc.
consult all products

Specifications

Light source

Blue, Green, UV LED (Intensity adjustable)

Objective lens

4X, 10 X, 20 X + Digital Zoom Spec.

Fluorescence

3 fluorescence

DAPI: Excitation 390/40, Emission 452/45 GFP: Excitation 466/40, Emission 525/50 RFP: Excitation 525/50, Emission 580LP

Camera

High-sensitivity monochrome CCD (Sony sensor 2/3”) 1,936 ⅹ1,456 pixels (2.8 M), 53 FPS, 14 bit

Stage

Automated X-Y-Z stage

Inter-changeable vessel holder

Exported formats

Image: JPEG, TIFF, BMP, PNG

Video: AVI

Raw data: CSV

PC requirement

All-in-One touch screen desktop

CPU: Intel Core i5-4590S Processor (Qual Core, 6MB,3.00GHz)

OS: Genuine Windows 8.1 64bit (ENG)

RAM: 8 GB (2×4 GB) 1600MHz DDR3L Memory

HDD: 1TB 2.5”  SATA (5,400 Rpm)

23” Full HD (1920 X 1080) with touch screen

Operating power

100 – 240 V, 1.5 A, 50/60 Hz

Electronic input

12VDC, 5.0 A

Dimensions

429 (W) X 310 (D) X 324 (H) mm

Weight

18.0 kg / 39.7 lbs

Operating environment

5 – 40 °C, 20 – 95 %

Contrast methods

Fluorescence and transmitted light
