RTS-1 Personal Bioreactor

Art No | BS-010158-A04

3'640.00 CHF

Brochure

RTS-1 - Single-Use Mini-Bioreactors with Real Time Cell Growth Logging and Innovative Reverse-Spin® Mixing Technology

The RTS-1 is a is personal bioreactor which provides “Reverse-Spin” type of agitation and logging of microbial growth in 50 ml tubes in real time.

Combined with a near-infrared optical system it is possible to register cell growth kinetics non-invasively in real time.

Reverse–Spin® mixing principle in 50 ml falcon tubes allows to achieve high kLa (h-1) up to 450 which is essential for efficient aerobic cultivation
Individually controlled bioreactor accelerates optimization process
Possibility to cultivate microaerophilic and obligate anaerobic microorganisms (not strict anaerobic conditions)
Reverse–Spin® mixing principle enables non-invasive biomass measurement in real time
Near-infrared optical system for cell growth kinetics
Free of charge software for storage, demonstration and analysis of data in real time
Compact design with low profile and small footprint for personal application
Temperature control for bioprocess applications
Task profiling for process automatization
Cloud data storage to remotely monitor the process of cultivation while at home or using a mobile phone

Software features:

Typical applications:

Measurement range	0–10 OD at 10–20ml volume (0–19 OD λ600 nm equivalent) 0–8 OD at 20–30ml volume (0–15.2 OD λ600 nm equivalent)
Measurement precision	±0.3 OD
Light source	NIR Light diode
Measurement wavelength (λ)	850 nm
Measurement periodicity per hour	1-60
Cultural media volume	10–30 ml
Temperature setting range	+25°C … +70°C
Temperature control range	5°C above ambient … +70°C
Temperature stability	±0.1°C
Display	LCD
Speed control range	50–2,000 rpm
Max. number of units connected to the software	10
Type of tube for aerobic cultivation	50 ml tube with membrane filter (TubeSpin® Bioreactor 50, TPP®)* *possible to use other manufacturer tubes of the same type
Type of tube for anaerobic cultivation	50 ml tube with membrane filter (TubeSpin® Bioreactor 50, TPP®)* *possible to use other manufacturer tubes of the same type
Minimum PC requirements	Intel/AMD Processor 1 GB RAM Windows Vista/7/8/8.1/10/11 USB 2.0 port
Optimal PC requirements	Intel/AMD Processor, 3 GB RAM Windows Vista/7/8/8.1/10/11 USB 2.0 port
Overall dimensions (W×D×H) \| Weight	130 x 212 x 200mm \| 1.7kg
Power consumption	40W
